The Outsunny 3-Seat Outdoor Sofa combines durability and comfort with its aluminum frame and plush, removable cushions. Designed for outdoor spaces, it provides ample seating for up to three people. Perfect for your patio, garden, or balcony, this sofa offers both style and relaxation.
Parts & Hardware List
- A – Left Armrest (x1)
- B – Right Armrest (x1)
- C – Left Backrest Support (x1)
- D – Right Backrest Support (x1)
- E – Left Seat Slat Panel (x1)
- F – Right Seat Slat Panel (x1)
- G – Support Bar (x1)
- H – M6*35 Screws (x4)
- I – M6*45 Screws (x2)
- J – M6*50 Screws (x2)
- K – M6*70 Screws (x2)
- L – M6*20 Screws (x2)
- M – Seat Cushion (x2)
- N – Back Cushion (x3)
- P – Washers (x20)
- Q – Nuts (x4)
- S – Allen Key (x1)
- T – Wrench (x1)
Assembly Instructions
- Please confirm that all components are present before beginning assembly.
- For the protection of your furniture, place all parts on a clean and smooth surface to prevent any damage.
- Please assemble the Outsunny 3-Seat Aluminum Outdoor Sofa with at least two people to ensure safety and ease of assembly.
- Do not confuse similar screws. Refer to the parts list for each screw size and quantity.
- Do not tighten bolts fully until all parts are connected to allow for proper alignment.
- After the assembly, periodically check all bolts and fittings. Re-tighten them as necessary to ensure the sofa remains stable.
- Follow these steps carefully to successfully assemble the Outsunny 3-Seat Aluminum Outdoor Sofa and enjoy its comfort and style.
Step 1: Attach the Left and Right Backrest Supports
- Take Part C (Left Backrest Support) and align it with Part D (Right Backrest Support).
- Insert the M6*70 screws (K) through the pre-drilled holes in the backrest support panels and place washers (P) onto the screws.
- Secure the parts together using M6 nuts (Q) and washers (P) on the screws as shown in the diagram.
- Tighten the screws, but do not fully tighten until all parts are connected and aligned.
Step 2: Attach the Left and Right Seat Slat Panels to the Backrest Supports
- Take Part E (Left Seat Slat Panel) and align it with the backrest support.
- Insert the M6*35 screws (H) through the pre-drilled holes in the slat panel and secure it using washers (P).
- Repeat the process for Part F (Right Seat Slat Panel), attaching it in the same manner with M6*35 screws (H) and washers (P).
- Tighten all screws, but do not fully tighten until all parts are securely connected.
Step 3: Attach the Seat Slat Panel to the Seat Frame
- Align Part E (Left Seat Slat Panel) with the seat frame.
- Insert the M6*50 screws (J) through the pre-drilled holes in the slat panel and secure it using washers (P) and M6 nuts (Q).
- Repeat the process for Part F (Right Seat Slat Panel), attaching it in the same manner with M6*50 screws (J), washers (P), and M6 nuts (Q).
Step 4: Attach the Armrests to the Seat Slat Frame
- Take Part A (Left Armrest) and align it with the seat slat frame.
- Insert the M6*35 screws (H) through the pre-drilled holes in the armrest and secure it using washers (P).
- Repeat the process for Part B (Right Armrest), securing it to the frame with M6*35 screws (H) and washers (P).
- Use M6*45 screws (I) to tighten and secure the armrests in the appropriate places.
Step 5: Attach the Support Bars to the Seat Frame
- Take Part G (Support Bar) and align it with the center of the seat frame.
- Insert the M6*70 screws (L) through the pre-drilled holes in the support bar and secure it using washers (P).
- Tighten the screws, but do not fully tighten until the support bar is securely attached to the seat frame.
Step 6: Attach the Cushions to the Sofa Frame
- Place Part M (Seat Cushions) onto the seat slat panels, ensuring they fit securely in place.
- Place Part N (Back Cushions) onto the backrest, aligning them properly with the frame for a snug fit.
- Ensure the cushions are positioned comfortably and evenly for optimal comfort.
Maintenance and Care
- Clean the cushion covers with mild detergent and air dry to keep their shape.
- Wipe the aluminum frame with a dry cloth to remove dirt and dust.
- For tougher stains on the frame, use a cleaner suitable for aluminum.
- Periodically check all screws and bolts, retighten any that are loose.
- If the sofa is not in use for a long time, cover or store it in a dry place.
- Avoid leaving the sofa exposed to extreme weather for prolonged periods.
Thank you for choosing the Outsunny 3-Seat Aluminum Outdoor Sofa (SKU: 84G-595V00CG). With proper assembly and care, your sofa will provide lasting comfort and style, perfect for your outdoor space. For assistance, replacement parts, or any questions, Aosom Customer Support is always ready to assist you.
You can also download the Outsunny 3-Seat Aluminum Outdoor Sofa Manual(PDF) for your reference.
FAQs
1. How can I prevent the armrests from wobbling?
If the armrests are wobbling, ensure that all screws and bolts securing the armrests to the seat frame are tightened properly. If the wobbling persists, check if the armrests are aligned correctly with the seat frame, and re-adjust if needed. Adding washers may also help if there is any play in the joints.
2. My sofa’s frame is not aligning properly, what should I do?
If the frame is not aligning correctly during assembly, double-check the positioning of each part according to the manual’s instructions. Ensure that all parts are aligned and that no screws are over-tightened before all parts are in place. Slight adjustments in positioning may be needed to ensure everything fits correctly.
3. How do I prevent rust on the aluminum frame?
To prevent rust on the aluminum frame, regularly clean the frame with a dry cloth to remove dirt and debris. If exposed to moisture, dry the frame immediately. Using a protective cover when not in use can also help shield the sofa from harsh weather conditions, preventing prolonged exposure to water.
