Thank you for choosing the HOMCOM Storage Trunk (SKU:838-444V82WT). Designed with modern simplicity and practical function, this wooden storage box helps you organize your home while serving as a stylish accent piece for bedrooms, living rooms, or entryways. Its durable construction and safety features ensure long-lasting reliability and user comfort.

Key Features:

• Spacious hidden compartment for blankets, toys, or accessories.
• Two alloy safety hinges hold the lid open securely at 60° or higher to prevent finger pinching.
• Smooth painted finish complements a wide range of décor styles.
• Side cut-out handles allow easy lifting and movement.

Safety Information

• Adult Assembly Required: Assembled only by adults. Keep small hardware away from children and pets.
• Lid Safety: This trunk includes two safety hinges that hold the lid open at angles of 60° or greater, preventing accidental closure.
• Weight Capacity:
  • Top surface: 264 lbs (120 kg)
  • Interior compartment: 88 lbs (40 kg)
    Exceeding these limits may result in damage or injury.
• Placement: Always position the trunk on a flat, stable surface.
• Maintenance: Check all fasteners monthly and retighten as needed.

Package Contents

Before assembling your HOMCOM Storage Trunk, verify that all components listed below are included. Report any missing or damaged parts to customer support.

Parts:

Hardware:

Assembly Instructions

Tools Required: Phillips screwdriver, rubber mallet, and protective gloves.

Recommended Assembly Time: 40–50 minutes Recommended People: 2 adults

Step 1: Attach Hinges and Support Bar

• Lay Panel (3) flat with pre-drilled holes facing upward.
• Align three hinges (C) evenly along the edge of Panel (3).
• Secure each hinge with three screws (D) using a screwdriver.
• Position Support Bar (6) along the inner top edge of the panel.

Step 2: Attach Support Bar to Panel (4)

• Place Panel (4) flat on the work surface with holes facing upward.
• Position Support Bar (6) along the top edge of Panel (4), aligning the pre-drilled holes.
• Insert four screws (E) through the holes in Support Bar (6) into Panel (4).
• Tighten all screws evenly using a Phillips screwdriver.

Step 3: Attach Support Bar to Side Panels (2)

• Place each Side Panel (2) on a flat surface with the handle cutout facing upward.
• Align Support Bar (7) along the inner top edge of each panel.
• Insert two screws (E) through the pre-drilled holes in Support Bar (7) into each Side Panel.
• Tighten the screws securely using a Phillips screwdriver.
• Repeat this process for both Side Panels (2) to complete two identical assemblies.

Step 4: Connect Side Panel (2) to Panel (3)

• Align Side Panel (2) with Panel (3) so that the pre-drilled holes are perfectly matched.
• Insert Bolts (A) through the outer holes of Panel (2) into the corresponding holes of Panel (3).
• Place Barrel Nuts (B) inside the side holes of Panel (3), ensuring the slot faces the bolt.
• Tighten the connection using the Allen Key (I) provided.
• Repeat the same process for the other Side Panel (2) to secure both sides of the frame.

Step 5: Attach Panel (4) to Side Panel (2)

• Position Panel (4) parallel to Panel (3) and align its holes with those on Side Panel (2).
• Insert Bolts (A) through the holes in Side Panel (2) into the corresponding holes of Panel (4).
• Place Barrel Nuts (B) into the side holes of Panel (4), aligning the slot with the bolt.
• Use the Allen Key (I) to tighten both bolts securely.

Step 6: Connect Opposite Side Panel (2)

• Align the remaining Side Panel (2) with the open ends of Panels (3) and (4).
• Insert Bolts (A) through the holes in Side Panel (2) into the connector holes of Panels (3) and (4).
• Place Barrel Nuts (B) into the holes on Panels (3) and (4), ensuring the slot faces the bolt.
• Insert Wood Dowels (H) into the pre-drilled alignment holes for added stability.
• Tighten all Bolts (A) evenly with the Allen Key (I) until both sides are securely connected.

Step 7: Insert Bottom Panel (5)

• Prepare the assembled frame structure with Panels (2), (3), and (4) securely fixed.
• Hold Bottom Panel (5) with the smooth side facing upward.
• Gently lower Panel (5) into the base of the unit, aligning it with the interior grooves.
• Ensure the panel fits snugly and sits flat without gaps or tilting.

Step 8: Attach the Top Lid (1)

• Position the Top Lid (1) above the assembled trunk with its pre-drilled holes aligned to the hinges on Panel (3).
• Attach the lid to the hinges using six screws (D),two per hinge.
• Tighten the screws securely with a Phillips screwdriver without overtightening.

Step 9: Install the Safety Hinge (G)

• Position the Safety Hinge (G) on the inner right side between the Top Lid (1) and Side Panel (2).
• Align the hinge ends with the pre-drilled holes on both panels.
• Secure the hinge using four screws (D) , two on the lid and two on the side panel.

Final Step: Assembly Complete

• Ensure all screws, bolts, and hinges are securely tightened.
• Check that the lid opens and closes smoothly with proper hinge support.
• Confirm the structure is stable and level on the floor.
• Clean the surface with a soft cloth to remove dust or fingerprints.
• Your HOMCOM Storage Trunk is now fully assembled and ready for use.

Operating Instructions

• Opening the Lid: Gently lift the front edge until hinges lock at 60° or higher.
• Closing the Lid: Lower slowly; hinges will control the descent.
• Storage Use: Organize soft items such as blankets, toys, or cushions. Do not exceed 88 lbs (40 kg) inside.
• Seating Use: Ensure the lid is fully closed and locked before sitting.

• Moving the Trunk: Lift using the cut-out handles on both sides; do not drag across the floor.

Maintenance Tips

• Cleaning: Wipe surfaces with a soft, damp cloth. Avoid solvents, bleach, or abrasive cleaners.
• Spill Care: Wipe spills immediately to prevent staining or warping.
• Hardware Check: Inspect and retighten screws monthly to maintain stability.
• Environmental Care: Keep away from direct sunlight or heat sources to prevent discoloration or deformation.

Troubleshooting Common Issues

Issue	Possible Cause	Solution
Lid does not stay open	Hinges misaligned or loose	Re-align and tighten hinge screws. Replace hinges if damaged.
Trunk feels wobbly	Uneven surface or loose hardware	Move to a level area and retighten all screws.
Lid squeaks or feels stiff	Dust buildup or hinge friction	Apply silicone spray or light oil to the hinge joints.

Warranty and Support

This HOMCOM product is manufactured by Aosom LLC.
Please review the warranty terms provided at purchase or visit the Aosom website for details.

You can also download the full HOMCOM Storage Trunk with 2 Safety Hinges Manual (PDF) for future reference.

For technical support, replacement parts, or product questions, contact Aosom LLC’s Customer Service and get friendly assistance.

FAQs

1. How do I ensure my storage trunk stays stable?

Check the surface before placing the trunk to ensure it’s flat and level. Tighten all screws and bolts regularly to avoid wobbling. This will prevent any instability.

2. What should I do if the storage trunk lid won’t stay open?

Re-align the hinges and tighten the screws to ensure proper positioning. If needed, replace the hinges if they’re damaged. Ensure the lid is not overloaded.

3. How do I prevent my storage trunk lid from squeaking?

Apply a small amount of silicone spray or light oil to the hinge joints. This will reduce friction and keep the lid moving smoothly. Wipe off any excess to avoid stains.

4. What’s the best way to clean the storage trunk?

Use a soft, damp cloth to clean the surfaces, avoiding harsh cleaners. Regularly dust off to prevent buildup. This keeps your trunk looking fresh and extends its lifespan.

5. How do I safely move the storage trunk?

Lift the trunk using the cut-out handles on both sides. Avoid dragging it across the floor to prevent damage. This method ensures safe, easy relocation without damaging the trunk.
