HOMCOM 5-Piece Rectangular Glass Kitchen Table and Chairs Manual-SKU: 835-255WT

Thank you for choosing the HOMCOM 5-Piece Rectangular Glass Kitchen Table and Chairs.
This set combines a sleek tempered-glass table with four matching upholstered chairs, blending modern aesthetics and daily practicality.Its metal frame offers stability, while the clear glass surface creates a light, spacious look perfect for contemporary dining spaces.

1. Safety Information Keep in Mind

• For indoor residential use only.
• Assemble on a flat, clean, dry surface.
• Keep all small hardware away from children.
• Do not exceed the maximum weight capacity of each chair or the tabletop.
• Keep away from open flames and direct heat sources.
• Clean gently with a soft cloth; avoid abrasive cleaners or chemicals.
• Regularly check and retighten all screws to maintain stability.

2. Before You Begin

• Prepare a spacious, dry work area and a protective sheet to avoid scratches.
• Verify that no parts are missing or damaged before assembly.
• Recommended assembly time: ≈ 60 minutes / 2 adults.
• Use only the included tools and hardware for best fit.

3. Package Contents

Box 1 of 2 – Table Components

Part No.	Description	Qty.
①	Tempered Glass Tabletop	1
②	Long Metal Frame Bars	2
③	Short Metal Frame Bars	2
④	Table Legs	2
A	Screws M6 × 50 mm (+ 1 spare)	8
B	Screws M6 × 25 mm (+ 1 spare)	4
C	Suction Pads (+ 1 spare)	6
D	Washers (+ 1 spare)	12
E	Allen Key	1

Box 2 of 2 – Chair Components

Part No.	Description	Qty.
⑤	Chair Backrests	4
⑥	Chair Seats	4
⑦	Front Leg Frames	4
⑧	Rear Leg Frames	4
⑨	Support Bars	4
F	Screws M6 × 18 mm (+ 1 spare)	32
G	Screws M6 × 40 mm (+ 1 spare)	8
H	Washers (+ 1 spare)	40
I	Allen Keys	4
J	Spring Washer (+ 1 spare)	40

Tip: Some spare hardware is included for convenience. Keep these for future maintenance.

4. Assembly Instructions

Step 1 – Assemble the Table Frame

• Align the two long frame bars (②) with the two table legs (④).
• Insert Screws A through the frame holes and secure them with Washers D.
• Tighten each screw using the provided Allen Key (E).
• Repeat on both sides to complete the rectangular frame

Step 2 – Attach the Support Bars

• Position the short support bars (③) between the assembled frame (②) sections.
• Insert Screws B through each connection point and secure with Washers D.
• Tighten evenly using the Allen Key (E) provided.
• Ensure all corners remain square and level before fully tightening the screws.

Step 3 – Install the Glass Tabletop

• Place six Suction Pads (C) evenly along the top edges of the assembled metal frame.
• Ensure each pad is pressed firmly into place to create a secure hold.
• Carefully lower the Tempered Glass Top (①) onto the frame, aligning it with the suction pads.
• Press gently to ensure the glass is evenly seated and stable.

Step 4 – Completed Table Assembly

• Verify that all screws are securely tightened and the glass tabletop (①) is properly aligned on all suction pads.
• Check that the table stands evenly and does not wobble.

 Final Check:

• Re-tighten all screws after 24 hours of use.
• Clean the glass surface using a soft, damp cloth and mild cleaner. Avoid abrasive materials.

Step 5 – Assemble the Dining Chairs

1. Align the Chair Back (⑤) with the Front Leg Frame (⑦) and Rear Leg Frame (⑧).
2. Insert the Screws (F) through the connection points, adding a Spring Washer (J) and a Flat Washer (H) to each screw.
3. Tighten screws using the Allen Key (I), turning clockwise until secure.
4. Ensure all legs are aligned and the chair sits evenly on the ground.
5. Do not overtighten, secure up to 75% tightness first, then finish tightening after all screws are in place for stability.

Step 6 – Attach the Seat Cushion

1. Position the Seat Cushion (⑨) onto the assembled Chair Frame from Step 5.
2. Align all holes on the seat with those on the frame.
3. Insert each Screw (G) through a Spring Washer (J) and a Flat Washer (H) before securing.
4. Tighten all screws using the Allen Key (I) until the seat is firmly attached.
5. Once the seat is secure, ensure the chair is stable and all screws are tightened to 100% for final firmness

Step 7 – Secure the Seat Base

1. Place the Seat Base (⑥) upside down on a clean, soft surface to avoid scratches.
2. Position the Leg Frame Assembly (from Step 6) on the bottom of the seat base, aligning all screw holes properly.
3. Insert Screws (F) through Spring Washers (J) and Flat Washers (H) into each hole.
4. Tighten securely using the Allen Key (I) in a diagonal pattern to ensure even pressure.
5. Once all screws are tightened to 100%, check that the seat base is firmly fixed.

Final Step – Assembly Complete

• Confirm all screws are securely tightened and the chair sits evenly on a flat surface.
• Gently test the stability by pressing on each corner to ensure there’s no wobble.
• Repeat this assembly for all four chairs.
• Clean any fingerprints or dust using a soft, damp cloth before use.

 Your HOMCOM 5-Piece Rectangular Glass Kitchen Table and Chairs (SKU: 835-255WT) Set is now fully assembled and ready for use.

6. Maintenance and Care

• Glass Surface: Use a soft cloth and non-abrasive glass cleaner.
• Metal Frame: Wipe with a damp cloth and dry immediately.
• Seat Upholstery: Clean with a mild soap solution and dry soft cloth.
• Retighten all screws periodically.
• Avoid placing hot items directly on the glass top.

7. Safety and Usage Notes

• Max Table Load: 120 kg (265 lbs)
• Max Chair Load: 120 kg (265 lbs each)
• Use the set on a flat floor only.
• Do not stand or lean on the chairs’ backrests.
• Always lift furniture when moving do not drag to avoid damage

You can also download the full HOMCOM 5-Piece Rectangular Glass Kitchen Table and Chairs Manual (PDF) for future reference.

For technical support, replacement parts, or product questions, contact Aosom LLC’s Customer Service and get friendly assistance.

FAQs

1. How can I stop my chairs from squeaking or wobbling?

Loosen all screws slightly, realign legs on a flat surface, and retighten gradually.Add felt pads under chair legs if your floor is uneven.Regularly inspect and re-secure joints every few months.

2. What should I do if a suction pad or screw is missing?

Use the spare parts included in the package first.If more are needed, contact Aosom Customer Service with your SKU number.Keep proof of purchase ready for quick replacement processing.

3. Can I place hot dishes directly on the glass table?

Avoid direct heat exposure to prevent cracking or discoloration.Always use heat-resistant mats or trivets under hot cookware.This protects both the glass surface and the suction pads below.

4. How do I clean the glass and metal without leaving streaks?

Use a soft microfiber cloth with a mild glass cleaner or vinegar solution.Dry immediately with a lint-free towel to prevent water marks.Avoid harsh abrasives that can scratch the metal or dull the glass shine.
